EUM-200SxxxDG 200W BIS Constant Current LED Driver
Features：
- Compact Metal Case with Excellent Thermal Performance
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable
- Output Lumen Compensation
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP66 / IP67 and UL Dry / Damp / Wet Location
- SELV Output
- TYPE HL, for use in a Class I, Division 2 hazardous (Classified) location
- 5 Years Warranty
Descriptions：
The EUM-200SxxxDx series is a 200W, constant-current, programmable IP66/ IP67 LED driver that operates from 90-305Vac input with excellent power factor. It is created for many lighting applications including high bay, high mast and roadway, etc. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, output over voltage, short circuit, and over temperature.
Models：
| Adjustable Output Current Range | Full-Power Current Range(1) | DefaultOutput Current | Input Voltage Range(2) | Output Voltage Range | Max.Output Power | Typical Effciency (3) | Typical Power Factor | Model Number (4)(5) | |
|---|---|---|---|---|---|---|---|---|---|
| 120Vac | 220Vac | ||||||||
| 53-700mA | 530-700mA | 530 mA | 90~305 Vac/ 127~300 Vdc | 142~378 Vdc | 200W | 94.0% | 0.99 | 0.96 | EUM-200S070DG (6) |
| 70-1050mA | 700-1050mA | 700 mA | 90~305 Vac/ 127~300 Vdc | 95~286 Vdc | 200W | 93.5% | 0.99 | 0.96 | EUM-200S105DG |
| 105-1500mA | 1050-1500mA | 1050 mA | 90~305 Vac/ 127~300 Vdc | 67~190 Vdc | 200W | 93.0% | 0.99 | 0.96 | EUM-200S150DG |
| 180-2800mA | 1800-2800mA | 2100 mA | 90~305 Vac/ 127~300 Vdc | 36~111 Vdc | 200W | 92.5% | 0.99 | 0.96 | EUM-200S280DG (7) |
| 350-5600mA | 3500-5600mA | 4200 mA | 90~305 Vac/ 127~300 Vdc | 18~57 Vdc | 200W | 92.0% | 0.99 | 0.96 | EUM-200S560DG (7) |
Notes：
(1) Output current range with constant power at 200W.
(2) Certified input voltage range: UL, FCC 100-277Vac; otherwise 100-240Vac.
(3) Measured at 100% load and 220Vac input (see below “General Specifications” for details).
(4) DG are UL Recognized, ENEC and CCC, etc. models.
(5) All the models are certificated to KS, except EUM-200S070Dx and EUM-200S105Dx.
(6) Only available with DG, and only with ENEC, CE, CB and CCC certificates.
(7) SELV output.
